Kyosho Mini-Z MR04 EVO2 Chassis Set (W-MM) 8500KV

Kyosho Mini-Z MR04 EVO2 Chassis Set (W-MM) 8500KV

MINI-Z MR-04 EVO2-W-MM Chassis – Full Model Upgrade for Unmatched Performance

The Ultimate Evolution of the MINI-Z Series!
Experience a new level of performance with the MR-04 EVO2 chassis, a full upgrade over the previous model. Building on the exceptional MR-03 layout, the MR-04 EVO2 introduces key improvements that significantly enhance stability, speed, and handling. With an optimized front suspension, lower center of gravity (C of G), and a sensored brushless motor, this model delivers performance like never before.

Key Features:

• Adjustable Front Tread & Wheelbase:
  Customize the chassis to suit your body type by adjusting the front lower and upper plates, as well as the steering tie rod. Choose between narrow or wide tread settings and fine-tune the wheelbase to achieve the perfect setup.

• Advanced Front Suspension Design:
  The MR-04 EVO2 features an integrated kingpin knuckle that improves camber stability. The swing of the current upper arm design optimizes the camber angle during cornering, while revised geometry (caster, trail, etc.) delivers smoother, more linear handling. New front springs with different hardness levels are available as options for further fine-tuning.

• Improved Front Knuckle & Bearings:
  The front knuckle features an integrated kingpin with optimized clearance for smoother operation. All seven ball bearings (3mm internal diameter) reduce rotational resistance, minimizing friction and enhancing performance.

• Lower Center of Gravity:
  A redesigned chassis lowers the mounting of the AAA batteries, improving stability and handling through corners. This change, in combination with the overall chassis shape, significantly enhances speed, control, and cornering performance compared to the MR-03.

• Ball Differential Included:
  The ball differential is standard, providing optimal rotational differences between the left and right rear wheels. This feature improves traction and provides moderate slip action when excessive load is applied. Additionally, the silver clear anodized finish on the aluminum parts adds a sleek, performance-inspired look.

• High-Speed Communication Support:
  The MR-04 EVO2 is designed to support high-speed communication with advanced transmitters and receivers, ensuring lightning-fast control response. Achieve transmission speeds of 0.99ms with KO units (ADV mode) and 0.9ms with Futaba units (EVO2 mode) — a vast improvement over the previous 2.6ms to 3.0ms.

Technical Specifications:

• Length: 124.5mm
• Width: 70?76mm
• Height: 31mm
• Motor Mount: MM
• Wheelbase: 98.0mm (LL)
• Tread (Front/Rear): 61.5?65.0mm / 61.5?65.0mm
• Tires (Front/Rear): φ25×8.5mm (sold separately) / φ25×8.5?11mm (sold separately)
• Gear Ratios: 7.3, 6.3, 5.5, 4.9:1
• Weight: 135.5g (without body, tires, or wheels)
• Motor: KYOSHO SPEED HOUSE XSPEED 85 (KV8500)

Included in the Kit:

• Factory assembled MR-04 EVO2-W-MM chassis
• KYOSHO SPEED HOUSE KV8500 brushless motor
• Parts set for changing front tread
• 6T, 7T, 8T, 9T pinion gears
• Wheel wrench
• Tools for pinion gears
• Spare wheel nuts

Required for Operation (sold separately):

• Transmitter
• Receiver unit (compatible with EVO/EVO2)
• ASC
• 4x AAA batteries for chassis
• Batteries for transmitter

Take your MINI-Z experience to the next level with the MR-04 EVO2 chassis. Whether you're a seasoned racer or a beginner, this upgraded model provides unparalleled control, precision, and speed. Perfect for enthusiasts who demand the best in performance!

Colour: Black

Compatible with: Kyosho Mini-Z MR-04 EVO2,
